Belt Conveyor Buffer Idler Roller Impact Idlers Rubber Rollers For Conveyor Belts
Impact IdlerBuffer RollerCarrying Idler For Belt Conveyor Idler Conveyor Rollers
Specification
| Product name | rubber rollers for conveyor belts |
| Tube Material | Q235 Carbon Steel |
| Shaft | 45# steel |
| Bearing Brand | HRB,SKF,FAG,etc. |
| Seal | Labyrinth Seal |
| Rubber Ring | Nature Rubber |
| Standard | JIS,CEMA |
| Certification | ISO9001,Environmental Protection Certification |
| Usage | Conveyor parts |
| Application | Coal, Mining, Cement,Crushing |
Besides we can manufacture the conveyor rollers and conveyor idlers according to the buyers' requirements,you can choose the size,length,material ,etc.as per your need
Roller is an important component of belt conveyor.It has many kinds and large quantity,can support conveyor belt and material weight.
| Product Specification |
| Item | rubber buffer conveyor roller | |
| Diameter | 89-159mm,can customize |
| Length | 190-1500mm,can customize |
| Material | Carbon steel |
| Seal | Multiple labyrinth seal |
| Bearing type | Deep Grove ball bearing |
| Gurantee | 12 months |
| Color | Customized |
| Certificate | ISO,CE |
| Advantages | waterproof,dustproof,smooth running,no noise,rotational resistance, axial float, shaft radial play
|
Features:
A) Bearing: deep groove ball and double sealing bearing 2RZ and 2Z with C3 clearance;
B) Sealing: multi-stage labyrinth seals achieve waterproof and dust proof
C) Lubrication: Grease is Lithium soap type grease with Rust Inhibitors, grease is permanent lubricant.
D) Color: roller surface could be painted any color as per customer request.
E) Each roller would be through strict inspection and test to ensure every out coming roller is of true high quality;
Quality design and build
Our focus on quality starts with sourcing only the best raw materials, rejecting anything that falls outside our strict tolerances.During manufacture your order is checked at each stage before passing through to the next process. This also contributes to our ability to meet orders on time.
Function
The role of idler is to support the weight of conveyor belt and material. The operation of idler must be flexible and reliable. Reducing the friction between conveyor belt and idler plays a key role in the service life of conveyor belt which accounts for more than 25% of the total cost of conveyor. Although the idler is a small part in the belt conveyor and its structure is not complex, it is not easy to make high quality idler.
There are several criteria to judge whether the idler is good or bad: the radial runout of the idler; the flexibility of the idler; the axial displacement
Application
Application: Belt Conveyor(Bulk Material Handling)
Application Environment: Quarry, Wharf, Coal mine,Batching plants,Steel plant........
Conveying Material: Coal, Stone, Mineral….
Q1. What is the advantage about your company?
A1. Our company has professional team and professional production line.
Q2. Why should I choose your products?
A2. Our products are high quality and low price.
Q3. The logo and the color can be customized?
A3. Yes, we welcome you to sample custom.
Q4. Any other good service your company can provide?
A4. Yes,we can provide good after-sale and fast delivery.
